High-Peak Frame Tents

Our High-Peak cover is designed with a high slope, a stylish peak and smooth curves to stand out from the rest. The High-Peak cover attaches the same way as the Tension. A mast pole is simply added to the crown to create the peak.

Trio® Frame System

Engineered and wind load tested up to 75 mph.*
Kentucky Tent Model Approved.
6005 T-6 anodized marine aluminum, 1¾” outside diameter, 1/8″ wall thickness with exclusive alignment line.

Color-coded end caps for easy identification of tubing lengths and keeping your tubing clean by keeping dirt out.
Patented cast aluminum fittings and detachable cast aluminum base plates.
Fail-safe steel snap button assembly.
Leg height is adjustable from 6’6″, 7′, 7’6″ and 8′.
Legs telescope down to 5′ for easy installation of tent cover and other accessories.
Pitch for the Trio: 10′ wide – 2’6″; 15′ wide – 3’9″; 20′ wide – 5′. Add center mast height for Hi-Peak style.
Additional cross-brace systems are available for any size Trio frame.
Stakes, ropes and ratchets are sold separately.

*Cross-bracing required on frames larger than 20′ x 20′ to meet wind load requirements.

Trio® Covers

Standard covers are manufactured of an exclusive high quality 1300 denier, 18oz. lacquer coated black-out vinyl material which makes the cover easier to handle, store, install and clean.
Clear Burlan 18oz. SkyLite™ with embedded filament lines that prevent cover expansion.
Available in 16oz. Solid Colors and Stripes. (See sidebar for color selections.)
UV treated, flame retardant that meets the California Fire Marshal Title 19 and NFPA 701, water repellent, mildew resistant.
Seams are 100% electronically welded.
Stainless steel buckles that prevent unsightly rust stains on your cover.
Double reinforced straps and buckles.
Vinyl grommets installed by R.F. welding on expandable covers.
Cover storage bag included.
